DRO PROS 1-2-3 Value! - Easiest to use Digital Readout - DRO Kits start at only $499 - Industry's best warranty!

Our Kit and Part Prices always beat Heidenhain Newall Acurite Sargon & Fagor!

We speak English - We answer our phones - FREE shipping on magnetic kits!

Compare all of our Digital Readouts! Click HERE



Scales up to 20 FEET LONG now available - Call for details



All Electronica Kits include magnetic scales:

Note the "hash marks" on the readhead and scale.

When installing the scale, make sure the readhead and scale "hash marks" are both installed on the same 'side' or the display might 'flicker'.





Click HERE to download  "How to Cut Magnetic Scales".

Click HERE to download "Cutting Magnetic Scales for a 2 Axis Mill" worksheet.

Click HERE to download the "Changing Electronica EL400 Scale Read Direction" document.



Magnetic scale technology combines the best of optical and inductive technology. Just like inductive or "ball scales", magnetic scales are impervious to coolant or liquid, yet are slimmer, and cost half as much! They're easier to mount, more durable, and on par pricewise with optical scales. In summary, magnetic scales combine all the advantages of the other technologies, without retaining the negative qualities of being higher priced, or difficult to install, that inductive or "ball scales" suffer from.



If that wasn't enough, the Electronica bracket kits are the best we've ever seen. Unlike the competitors bracket kits, Electronica brackets are individually machined for accuracy, not cast. Our "Library" page includes a complete parts list and exploded assembly diagram - in short, no more missing parts or time consuming "how does this bracket fit together" sessions!



In summary, the Electronica Magnetic Scale Digital Readout kit is a revolutionary change to digital readouts as you know them! With the industries lowest profile reader head, this is a game changer!



Magnetic scales:

Do not contain glass - much more durable than any other type scale.

Are coolant and dust proof - have a full IP-67 rating, meaning they can't get contaminated like glass scales.

Can be easily cut to the length you need - no more "hanging off" the end of the cross slide - custom fit to your application!

Easy to mount - the scale is surface mounted directly to the table, not offset like other brands require!



Resolution:

Grinder kits come standard with 1 micron (0.00005") resolution magnetic scales



The Electronica Grinder packages include everything you need - a display head, mounting arm, power cord, detailed installation manual, a super detailed operators manual, shields, mounting hardware, brackets, etc. Additionally, all Electronica displays have a USB port on the back, ensuring it won't become obsolete when a new software update is released.



Stop paying our competitors outrageous prices! Outfit your machine today with magnetic scales at a DRO PROS price!



Electronica Magnetic Scale 2 Axis Grinder Kit:



EL400 Grinder Kit





Items are shown out of their protective boxes to better illustrate what's included.

Display cover, and installation instructions included but not shown.

All kits ship in original factory packaging and boxes.

Magnetic Scales can be easily cut to length and can't be contaminated!

Scales up to 20 FEET LONG now available - Call for details

10" x 20" $999
Cross Axis Brackets:
Vertical Axis Brackets:
Recommended EL400 Documents:

How to Cut Magnetic Scales

2 Axis Mill Worksheet

Changing EL400 Scale Read Direction









Electronica 400 "Machine Specific" 2 Axis Grinder Display:

- The proper terminology for describing a 2 axis grinder kit are X and Z.

- This display has the 'proper' X and Z buttons on the front panel.

- The back of the display has the proper connections for the X and Z axis.

- The front display has "Quick Zero" buttons for both the X and Z axis.

- The lower eight function keys are grinder specific.



The following drills and taps are helpful when installing Electronica kits:



Scale Endcaps M3 x .5 plug tap    Enco Part #510-1218

Mounting the Scales M4 x .7 plug tap    Enco Part #510-1272
  M4 x .7 bottom tap Enco Part #510-1170
  3.30mm drill for M4 taps Enco Part #317-8273

Scale & Readhead Brackets M6 x 1.0 plug tap Enco Part #510-1299
  M6 x 1.0 bottom tap Enco Part #510-1213
  5.00mm drill for M6 taps Enco Part #317-8286



Benefits of Magnetic Scales

  Magnetic Scales Glass Scales Inductive Scales
Profile 1-1/4" thick 2-1/8" thick 2-7/8" thick
Ease of installation Flat scale "bar" easily mounts directly to machine Scale and readhead joined together ? cannot be disassembled Round "bar" must be offset / cannot be mounted flat against the machine
Price Complete kit starts at only $760 ~ $700 $1,500 +
Cost to repair Readhead and / or scale can be purchased separately Readhead and scale must be purchased as a complete assembly Parts extremely expensive
Resistance to contaminants Impervious to contaminants Optical technology susceptible to contamination Impervious to contaminants
Can scales be cut  to a custom length? Yes No No
Scale durability Virtually indestructible Glass prone to breakage, contamination Rod susceptible to damage
Overall length 2.5" longer than travel 5" longer than travel 10" longer than travel
Upgradeable software Convenient USB Not available Not available
Bracket system Powder coated black, custom brackets  "Universal brackets" require extensive modification Complicated bracket system must be "offset"

There are currently three different scale types available for digital readout systems. They are magnetic, glass, and inductive. Glass scales rely upon an optical encoder and receiver mounted inside of an aluminum extrusion. If the scale becomes contaminated by coolant, oil or dust, they are rendered useless.

Inductive scales are impervious to contamination. The disadvantages are they're bulky, expensive, and difficult to mount.

Magnetic scales combine the best of optical and inductive technology. Magnetic scales are impervious to coolant, liquid or dust, yet are slimmer than either of the other two technologies. They're easier to mount, more durable, and can be broken down into convenient lengths for shipping. The first thing customers notice with magnetic scales is that the readhead and the scale are completely separate components. This means mounting magnetic scales is easier than any other type scale - since the readhead mounts separately from the scale, mounting is much quicker, and a whole lot easier! Prior to Electronica, magnetic scales were prohibitively expensive. Today, they are on par pricewise with optical scales. In summary, magnetic scales hold all the advantages of the other technologies, without retaining the negative qualities of being higher priced or difficult to install that inductive scales suffer from.

Picture of a New Glass Scale:

Picture of a new glass scale. Notice the mirror finish along the walls inside the scale.



Picture of a Glass Scale that's been improperly used in a contaminated environment:

Picture of a glass scale contaminated by hundreds of debris particles after being placed in service less than 3 months. The inside of this scale should be a mirror shiny finish, as shown above. Even a single bit of debris can cause a glass scale to stop reading correctly. Unfortunately, a contaminated glass scale will continue to display position, albeit an incorrect one, leaving the operator unaware of the malfunction. The solution, of course, is to use magnetic scales. Magnetic scales are designed to operate in the harshest and most extreme environments. Not only are magnetic scales unaffected by debris or contamination, they're also protected against submersion in coolant or liquids.







The height or head dimension of the readhead is critical to a clean DRO installation. Magnetic scale technology eliminates the bulky optical sensors common to traditional readheads.

A slim design means the readhead can be mounted close to the machine, increasing travel and tool efficiency.

Slimmer profile readheads are also much less likely to get damaged from dropped tools or workpieces.

Magnetic readheads retain the advantage of being impervious to coolant, but aren't bulky or expensive like inductive or optical scales.







The overall required mounting height is much less than optical or inductive scales.



Magnetic scale height is less than half that of inductive scales.





"Required End Clearance" is the 'dead space' between the center of the readhead and the end of the scale. The more "Required End Clearance" a scale requires, the longer the scale becomes.




Electronica Digital Readout Features:

   l Inch/Metric Display    l Line Hole Function
   l Axis "Quick-Zero" Keys    l Grid Function
   l Axis Set    l Linear Bolt Hole Function
   l User Selectable Resolution    l Arc Contouring Function
   l Half Function    l Radius / Diameter
   l Distance to Go    l Tool Offset
   l Center of Circle    l Taper Function
   l Center of Line    l Polar Coordinates
   l ABS/INC Coordinate Display Switch
   l Easy Setup Mode
   l Calculator

   l Axis Summing

   l Sub Datum Memory    l Vectoring Function
   l Power Off Memory    l Pre-Set Depth (PSD)
   l Bolt Hole Circle    l Touch Probe Input
   l Bolt Hole Arc    l Linear Error Compensation
   l Fault / Error alarm    l USB Port







Electronica Digital Readout Basic and Special Functions Explained:



Inch/Metric Display - Allows the operator to choose between inch and metric display. Resolution is .0002" or .005mm.

Axis "Quick-Zero" Keys - Unique to the 400 series displays, these 'one-touch' keys enable the user to quickly zero the selected axis.

Axis Set - Allows operator to manually input desired dimension / coordinate.
Fine / Coarse Resolution - Turns off the last decimal digit (coarse resolution) in which fine resolution is excessive.
Half Function - Automatically calculates the center of the workpiece after the edges are located.

Distance to Go - Provides a 'Near Zero Warning' to the operator as the machine nears a preset point.

Center of Circle - Allows the user to find the center of a circle after 'touching' 3 points on the circle.

Center of Line - Allows the user to find the center of a line after locating the end points.

ABS/INC Coordinate Display Switch - Allows the operator to switch between absolute and incremental display. 'Absolute' display references the work piece zero coordinate you designate. You may choose the absolute center point of your workpiece or perhaps a corner of your workpiece, the decision is yours. Incremental display references any arbitrary coordinate/position without losing your designated zero point. For example, to locate a point exactly in the middle of your workpiece you would most likely use 'absolute' display to locate the point. To locate points exactly .78 distant from an arbitrary point somewhere in the middle of your workpiece, you would then switch to 'incremental' display, designate the present position as a zero point, and then simply move your workpiece until .78 was displayed.

Calculator - The display includes a built in calculator function which provides normal mathematical functions such as: add, subtract, multiply, divide, sin, cosine, tangent, etc.

Sub Datum Memory - Allows the user to store up to 1,000 reference points. This greatly simplifies machining of repetitive parts.

Power Off Memory - This function allows the operator to store the work piece zero position in memory. If the machine is turned off at night or there is a power failure, the zero reference points can be recovered without having to reestablish the work piece zero point.

Bolt Hole Circle - Allows the operator to drill a circular pattern of holes from a designated center point.
Bolt Hole Arc - Allows the operator to drill a pattern of holes in a semi-circle or arc from a designated center point.

Line Hole Function - Allows the operator to drill a straight line of holes along any desired angle.

Grid Function - Allows the operator to drill a grid of holes along any desired angle.

Linear Bolt Hole Function - Similar to Line Hole Function, allows the operator to create an equally spaced pattern of holes.

Arc Contouring Function - Enables the user to make an arc or bevel cut along the edge or top of a workpiece.
Radius / Diameter - When measuring radii or diameter, enables the operator to display twice the real displacement.

Tool Offset - Unique to lathe displays only, automatically compensates coordinate system for tool length and diameter. Allows 9 presets.

Taper Function - Unique to lathe displays only, automatically calculates the taper of a workpiece.

Polar Coordinates - Allows user to measure distance in a polar coordinate measuring system.
Easy Setup Mode - Enables access to special functions, such as swapping or 'reversing' the direction a scale reads.

Axis Summing - Unique to 4 axis displays only, allows the 'coupling' or 'summing' of any two axis to read as one.

Vectoring Function - Unique to 3 axis lathe displays only, allows the 'coupling' or 'summing' of Z and Z' to read as one.

Pre-Set Depth (PSD) - Unique to EDM displays only, used to control a relay at a pre-set depth setting.

Linear Error Compensation - Used to 'calibrate' the scales, Linear Error Compensation provides improved display accuracy. Electronica's method of inputting LEC correction is the simplest we've ever seen. Other brands have you calculate multiple complex "correction factors" that slowly correct you towards your desired calibration. Literally, this 'old' way of calibration can take hours, even days. Electronica's method is to simply measure a predetermined distance, and then enter that distance into the display - the 'correction factor' is automatically calculated and applied in the background - simple, easy and best of all, fast!

USB Port - Common to all Electronica displays, a USB port allows easy software updates, ensuring your DRO won't become obsolete!
